Intumescent fire strips are tested by Efectis Era.
Certificate Nr: EAA-1600-000X
INTUFLAME
Intumescent Fire Strips
Certified strip to prevent air circulation and the escape of hot gases and smoke for fire doors and buildings.
- Tested
- Easy application
- Different sizes
Our product is based on the chemistry of expandable graphite. It is flexible and thus easy to install and comes with self-adhesive backing. Our intumescent fire strip is designed to expand to many times it’s installation size to prevent air circulation and the escape of hot gases and smoke between doors, frames and other potential gaps where fire resistance is required. In addition our fire strip ensures smoke and toxic gas reduction.
Accreditations
Our products have been extensively tested to the latest EU standards and have achieved Efectis Era approval assessed against the requirements of the technical schedules.
Test Information
The thickness of the test pieces ranged from 1.5mm through to 40mm. The test pieces resisted fire for 180 minutes with no significant change and maintained integrity in accordance with criteria list E when the test was terminated.
Test Result: EN1366-4 2006. A1 2010 (E).
EN1363-1:1999, Fire resistance test-Part1: General requirements; EN 1363-2, Fire resistance tests-Part2: Alternative and additional procedures, EN ISO 13943:2000, Fire safety-Vocabulary (ISO 13943:2000)
Standard Sizes
Thickness | Roll | Length | ||
|---|---|---|---|---|
1,5 mm x 15 mm | 25 meters roll | 300 meters in the box | ||
2 mm x 15 mm | 25 meters roll | 300 meters in the box | ||
1,5 mm x 20 mm | 25 meters roll | 225 meters in the box | ||
2 mm x 20 mm | 25 meters roll | 225 meters in the box | ||
1,5 mm x 30 mm | 25 meters roll | 150 meters in the box | ||
2 mm x 30 mm | 25 meters roll | 150 meters in the box | ||
Download PRONIL INTUFLAME brochure
Documents
You can download all related product documents here. For additional documents contact with us.
Tests
Intumescent fire strips are tested by Efectis Era.
Certificate Nr: EAA-1600-000X
