ACR

Hydrophilic Waterstop Tape, Plugs and Rings

New generation high performance waterstops which expanding up to 900% when in contact with water.

Pronil ACR is a new generation high performance acrylic polymer based expanding tape. It expands up to 900% when in contact with water. In a totally dry state, Pronil ACR will shrink to it’s original installation dimension and re-expand on wetting. Pronil ACR is used in concrete construction for the sealing of construction joints including wall to base connections, pipe entry systems, sealing of openings and interface sections between existing and new concrete. Pronil ACR is easily stored in it’s original moisture-proof wrap in cool, dry conditions away from sunlight.

ACR-300

Tap water, wet/dry difference ≥300%
Concrete water (14 days) ≥200%
3% salt water (14 days) ≥100%
Water pressure resistance (14 days): 7 bar
Colour: Red

ACR-600

Tap water, wet/dry difference ≥600%
Concrete water (14 days) ≥400%
3% salt water (14 days) ≥200%
Water pressure resistance (14 days): 7 bar
Colour: Yellow

ACR-900

Tap water, wet/dry difference ≥1300%
Rain water (14 days) ≥900%
Concrete water (14 days) ≥600%
3% salt water (14 days) ≥300%
5% salt water (14 days) ≥260%
10% salt water (14 days) ≥240%
Water pressure resistance (14 days): 7 bar
Colour: Blue

PLUGS & RINGS

Day 7 ≥300%
Wet/dry difference ≥300%
Water pressure resistance (14 days): 7 bar
Colour: Red, Blue

Advantages

Conformable, can be used on a variety of irregular substrates.
Forms an impermeable barrier against water in concrete.
Excellent compliance with deformed surfaces and joints.
Saves time and labour.
Easy to apply.
Simple overlap jointing on site.
No hardening time required.
No welding required.
Swells in salt water.

Self-Adhesive Option

Standard Sizes

Thickness	Roll	Length
05 mm x 20 mm	20 meters roll	140 meters in the box
10 mm x 20 mm	10 meters roll	70 meters in the box
20 mm x 20 mm	5 meters roll	25 meters in the box
20 mm x 25 mm	5 meters roll	25 meters in the box
20 mm x 30 mm	5 meters roll	25 meters in the box
30 mm x 30 mm	5 meters roll	20 meters in the box
05 mm x 100 mm	20 meters roll	40 meters in the box

Wall Application

Tunnel Application

Technical Data

The increase in volume was measured when specimens were immersed in tap water at 23°C over a 28 day period. Recovery volume was measured when the specimens were removed from the solution and air dried over a 28 day period. This method was repeated over three cycles. The percentage change in volume calculations are all based on the initial volume.

Application Temperature: -10°C / 50°C
Density: 1,40 g/cm³
Shore: 50

The expansion rating is affected according to CaCO₃ and salt content. Contains no traces of Bentonite.

Our acrylic waterstops are tested by BBA (British Board of Agrément).

BBA Test No: T1-61007

BBA Test Results

Water Pressure Test
